SKYLINE TYPE R
The DA-SKYLINE TYPE R sliding door system features a hidden frame and narrow profiles, giving the construction an on-trend, minimalist look offering panoramic views. Doors created using this structure give a building an exceptional style and enhance the status of an entire development.
Door leaves built with the DA-SKYLINE TYPE R are concealed in the bottom and top frames. If the variant equipped with a motor or with a lock on the mullion is selected, then the side profiles are also concealed. The frame itself has been designed for maximum user comfort and is therefore as slender as can be achieved, with a depth of just 23mm. The width of the mullion has also been reduced to a minimum, with the only visible joint measuring a mere 25mm. The structural depth of the door profiles is seventy-one millimetres and, of the frames, one hundred and ninety millimetres.
FUNCTIONS AND AESTHETICS:
- the door frame is built into the walls, floors and ceiling
- the leaf profiles are completely hidden in the upper and lower frames
- when the automatic drive unit option is selected, or the mullion features a locking mechanism, the leaf profiles remain invisible at the sides of the structure
- the width of the mullion where the leaves meet is 25 mm
- a convenient, shallow, 23 mm deep frame
- the maximum leaf weight is 500 kg for manually operated leaves and 700 kg for automatically operated
- glazing options range from 52 to 60 mm
- the structural depth of the door profiles is 71 mm for the leaves and 190 mm for the frame
- the door leaves are made using state-of-the-art insulation material with high thermal parameters
- the cutting-edge sliding seals used in the frame are aesthetically pleasing and silent in use
- the rollers the leaf moves along are available in stainless steel or black polyamide
- there are two locking; manual, using BT Lock hardware or fitted to the mullion
- the motor is equipped with a radio receiver and security radar
- state-of-the-art drainage system, complete with guttering
- system brackets with height regulation
- the structural base has excellent thermal isolation
- the system features a ‘zero mullion’, which makes it possible to use external venetian and roller blinds like the ALUPROF Skyflow and Skyroll.
