hst lift- slide patio door

---

                              Uw*

0,83 W/(m2k)

   Glazing package

  4/18/4/18/4

Threshold
62 mm made of vinyl

Installation depth
Sash: 82 mm; Frame: 194 mm

Max. door height

2,7 m for white colour and 2,5 m for other colours

Max. door width

 6,5 m

               Max. sash size

6,5 m2

V-perfect  welding

    Uw*

           0,77 W/(m2k)

  Glazing package

     4/18/4/18/4

Threshold
62 mm made of vinyl

Installation depth
Sash: 82 mm; Frame: 194 mm

Max. door height
2,7 m for white colour and 2,5 m for other colours

Max. door width        Max. sash size
6 m                                6,5 m2

V-perfect welding

Uw*

  0,84 W/(m2k)

   Glazing package

    4/18/4/18/4

Threshold
24 mm aluminium with thermal break

Installation depth
Sash 82 mm | Frame 194 mm

Max. door height
2,66 m for whites and 2,46 m for other colours

Max. door width        Max. sash size
6 m                                6,5 m2

V-perfect welding
